Labs

Workshop

3D printing machine (300x300x300mm)

Capable of printing 3D objects of size upto 300mm x 300mm x 300mm with raw material PLA (Polylactic Acid)

3D printing machine (400x400x800mm)

Capable of printing 3D objects of size upto 400mm x 400mm x 800mm with raw material PLA (Polylactic Acid)

Laser cutting machine (1400x900mm)

Capable of perfroming through cuts and etching using a high powered laser on materials upto 15mm thick.

CNC Router (8’x4’)

CNC routers can perform the tasks of many carpentry shop machines such as the panel saw, the spindle moulder, and the boring machine.

Colour Laser printer A3 size

Produces color prints on upto A3 size paper. Also has scanning capabilities.

Black & while Laser printer A3 size

Produces B/W prints on upto A4 size paper.

Desktop PC

i7 Destop with latest windows 10

Thickness planer

Thickness planer is a woodworking machine to trim boards to a consistent thickness throughout their length and flat on both surfaces.

Multipurpose planer

Multipurpose planer has the functions of sawing, surface‐planing, thicknessing,mortising, sharpening,profiling,etc

Working bench

A workbench is a sturdy table at which manual work is done.

Anvil

An anvil is a metalworking tool (often referred to as a doink) consisting of a large block of metal (usually forged or cast steel), with a flattened top surface, upon which another object is struck (or "worked").

Electric Welding machine

Welding machines or welding guns or welders are among the most essential tools for a welding professional. Welding machines generate heat that melts metal parts, so that these parts can be joined.

Hand operated drill

A traditional wheel brace or hand drill, with hollow wooden handle and screw‐on cap used for storing bits

Bench vice

Bench vices are used to hold a workpiece stationary, is an integral tool in many woodworking and other manufacturing applications.

Power operated jig saw

A jigsaw is a versatile and easy‐to‐use power tool that allows us to make straight or intricate curved cuts for craft projects or other woodworking tasks.

Pottery wheel

A workbench is a sturdy table at which manual work is done. It May be used for general woodworking but may be specialized for joinery, patternmaking, stairbuilding, carving, carpentry or trim work.

Electrical Sander

An electric sander is a power tool used to smooth and finish surfaces. To remove material from a surface, the sander moves a piece of sandpaper or another abrasive rapidly, often in a circular motion.

Triangular file

Triangular files have three tapering sides. They are used to file the surfaces of acute internal angles. Small triangular files are also used to sharpen hand saws.

Rasp file

Rasp file have a series of individual teeth produced by a sharp, narrow, punchlike chisel. Their very rough cut is suited to the fast removal of material from soft substances, such as wood, aluminum.

Flat file

Flat file is made slightly tapered both in width and thickness. Double cut teeth are cut on the face and simple‐cut teeth are cut on the edge.

Pincer

Pincers are a hand tool used in many situations where a mechanical advantage is required. They are used to pinch, cut or pull out nails from wood without damaging the surface.

Set square

Set sqaure is used for marking out right angles before any joint is cut. It can also be used for marking straight lines and checking straight edges. The tool is often used alongside other tools

Jack plane

A jack plane is a general-purpose bench plane. It can take over from where the scrub plane leaves off, being used for shaving off smaller amounts of wood to reduce a piece to the desired size and for initial smoothing.

Electric Drill

A drill or drilling machine is a tool primarily used for making round holes or driving fasteners. It is fitted with a bit, either a drill or driver, depending on application, secured by a chuck. Drills vary widely in speed, power, and size

Hack Saw

A hacksaw is a hand‐powered, small‐toothed saw used for cutting metal pipes, rods, brackets, etc. Hacksaws can also cut through plastic.

Flat Chisel

A flat chisel is used to obtain a flat and finished surface (as on wood or stone).

Dove‐tail Chisel

Dove‐tail Chisel used to create and clean out dovetails. Due to the triangular cross‐section the blade easily fits the tight corners of the dovetails. The back of the blade is slightly hollow to minimize friction.

Guage Chisel

Gouges are designed to carve grooves without the corners of the tool digging into the wood. This serves a few purposes. Gouges remove excess wood quickly, especially from a flat surface, where the corners of a flat chisel would dig in and get stuck.

Adjustable pipe wrench

Adjustable pipe, or Stillson, wrench is used to hold or turn pipes or circular bars. This wrench has serrated jaws, one of which is pivoted on the handle to create a strong gripping action on the work.

Auger

An auger is a spiral‐shaped tool that is used to drill holes into the ground and other surfaces or materials. The spiraling metal shaft with a blade at the end of the device is known as a “flighting"

Spanner Set

The spanner is a hand‐held tool used to provide grip and tighten or loosen fasteners. It gives a mechanical advantage in applying torque to turn objects. The tool is used in turning rotary fasteners like nuts and bolts.

Glass Cutter

A glass cutter is a tool used to make a shallow score in one surface of a piece of glass (normally a flat one) that is to be broken in two pieces, for example to fit a window. The scoring makes a split in the surface of the glass which encourages the glas

Ratchet Brace

Ratchet brace is a hand‐tool used to drill holes or nails into wood. The linear motion of its crank‐shaped handle can provide ample torque when drilling.

Angle Grinder

Angle Grinder is a handheld power tool used for grinding and polishing. Although developed originally as tools for rigid abrasive discs, the availability of an interchangeable power source has encouraged their use with a wide variety of cutters and attach

Circular Saw

A circular saw is a tool for cutting many materials such as wood, masonry, plastic, or metal and may be hand‐held or mounted to a machine. Circular saw blades are specially designed for each particular material they are intended to cut and in cutting wood

Screw Driver ‐ Multiple Size

A screwdriver is a tool, manual or powered, used for driving screws. A typical simple screwdriver has a handle and a shaft, ending in a tip the user puts into the screw head before turning the handle.

RD Works V8

RDWorks v8/LaserWORKS v8 provides users a convenient tool for the manual sorting of graphic objects. Used to guide laser cutters to perform intricate tasks

Autodesk Artcam

ArtCAM software is a single solution for designers, makers, and small businesses looking to create 3D reliefs and decorative woodwork. ArtCAM is a unique software program which enables you to create impressive, high‐quality three‐dimensional products star
